ART-B22-D70

LEM USA, Inc.

Image may be representation. See specifications for product details.

Product Overview

Part Number:	ART-B22-D70
Manufacturer/Brand:	LEM USA, Inc.
Product description	CURR SENSE XFMR FLEXIBLE COIL
Datasheets:	ART-B22-D70.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	717 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 717 pcs

Reference Price (In US Dollars)

1 pcs: $43.678

5 pcs: $41.377

10 pcs: $36.78

25 pcs: $34.481

50 pcs: $33.332

100 pcs: $32.182

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$43.678

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of ART-B22-D70

Part Number	ART-B22-D70	Manufacturer	LEM USA, Inc.
Description	CURR SENSE XFMR FLEXIBLE COIL	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	717 pcs	Data sheet	ART-B22-D70.pdf
Type	Non-Invasive (Split Core)	Turns Ratio - Primary:Secondary	Rogowski Coil
Termination Style	Wire Leads	Size / Dimension	2.205" L x 1.326" W (56.01mm x 33.69mm)
Series	ART	Ratings	-
Other Names	398-1188 90.M4.99.000.0 ART B22 D70 ART-B22-D070	Mounting Type	Free Hanging (In-Line)
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Inductance	180µH	Height - Seated (Max)	0.744" (18.91mm)
Frequency Range	50/60Hz	Energy Time (E.T.)	-
Detailed Description	Rogowski Coil Current Sense Transformer 50/60Hz 55 Ohm 180µH Free Hanging (In-Line)	DC Resistance (DCR)	55 Ohm
Current Ratio	-
