A22NW-3RM-TGA-G101-GC

Omron Automation & Safety

Image may be representation. See specifications for product details.

Product Overview

Part Number:	A22NW-3RM-TGA-G101-GC
Manufacturer/Brand:	Omron Automation & Safety
Product description	SWITCH SELECT 3POS DPST-NO 10A
Datasheets:	A22NW-3RM-TGA-G101-GC.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	3593 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

Download Product Details PDF

In Stock 3593 pcs

Reference Price (In US Dollars)

1 pcs: $9.792

10 pcs: $9.122

25 pcs: $8.988

50 pcs: $8.853

100 pcs: $7.78

250 pcs: $7.512

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:
Qty:

Total:$9.792

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of A22NW-3RM-TGA-G101-GC

Part Number	A22NW-3RM-TGA-G101-GC	Manufacturer	Omron Automation & Safety
Description	SWITCH SELECT 3POS DPST-NO 10A	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	3593 pcs	Data sheet	A22NW-3RM-TGA-G101-GC.pdf
Voltage Rating - DC	24V	Voltage Rating - AC	120V
Type	Standard	Termination Style	Screw Terminal
Switch Function	On-Off-Off, Off-Off-On	Series	A22NW
Panel Cutout Dimensions	Circular - 22.30mm Dia	Other Names	A22NW-3RM-TGA-G101-GC-ND A22NW3RMTGAG101GC Z6203
Operating Temperature	-25°C ~ 55°C	Number of Positions	3
Mounting Type	Panel Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	300,000 Cycles	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	IP66 - Dust Tight, Water Resistant	Illumination Voltage (Nominal)	24 VAC/DC
Illumination Type, Color	LED, Green	Illumination	Illuminated
Features	Bezel - Round, Green Knob	Electrical Life	300,000 Cycles
Detailed Description	Selector Switch 3 Position DPST-NO 10A (AC), 8A (DC) 120V Panel Mount	Depth Behind Flange	45.30mm
Current Rating	10A (AC), 8A (DC)	Circuit	DPST-NO
Approvals	CCC, CE, cULus, TUV
