G3T15AP

NKK SwitchesNKK Switches
NKK Switches
Image may be representation. See specifications for product details.

Product Overview

Part Number: G3T15AP
Manufacturer/Brand: NKK Switches
Product description SWITCH TOGGLE SPDT 0.4VA 28V
Datasheets: G3T15AP.pdf
RoHs Status Lead free / RoHS Compliant
Stock Condition 16896 pcs stock
Ship From Hong Kong
Shipment Way DHL/Fedex/TNT/UPS/EMS
Download Product Details PDF
In Stock 16896 pcs
Reference Price (In US Dollars)
1 pcs
$1.71
Request Quote
Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]
  • Target Price:(USD)
  • Qty:
Total:$1.71

Please give us your target price if quantities greater than those displayed.

  • Part Number
  • Company Name
  • Contact Name
  • E-mail
  • Message

Specifications of G3T15AP

Part Number G3T15AP Manufacturer NKK Switches
Description SWITCH TOGGLE SPDT 0.4VA 28V Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 16896 pcs Data sheet G3T15AP.pdf
Voltage Rating - DC 28V Voltage Rating - AC 28V
Termination Style Gull Wing Switch Function On-Mom
Series G3T Panel Cutout Dimensions -
Packaging Tray Operating Temperature -30°C ~ 85°C
Mounting Type Surface Mount Moisture Sensitivity Level (MSL) 1 (Unlimited)
Lead Free Status / RoHS Status Lead free / RoHS Compliant Ingress Protection -
Illumination Voltage (Nominal) - Illumination Type, Color -
Illumination Non-Illuminated Features Process Sealed
Electrical Life 50,000 Cycles Detailed Description Toggle Switch SPDT Surface Mount
Current Rating 0.4VA (AC/DC) Circuit SPDT
Bushing Thread Unthreaded Actuator Type Standard Round
Actuator Material Polyphenylene Sulfide (PPS) Actuator Length 3.81mm
