RT9629AZQW

Richtek

Image may be representation. See specifications for product details.

Product Overview

Part Number:	RT9629AZQW
Manufacturer/Brand:	Richtek
Product description	IC FET DVR 3CH SYNC BUCK 24WQFN
Datasheets:	RT9629AZQW.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	57877 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

Download Product Details PDF

In Stock 57877 pcs

Reference Price (In US Dollars)

1 pcs: $0.629

10 pcs: $0.568

25 pcs: $0.507

100 pcs: $0.456

250 pcs: $0.406

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$0.629

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of RT9629AZQW

Part Number	RT9629AZQW	Manufacturer	Richtek
Description	IC FET DVR 3CH SYNC BUCK 24WQFN	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	57877 pcs	Data sheet	RT9629AZQW.pdf
Voltage - Supply	4.5 V ~ 13.2 V	Supplier Device Package	24-WQFN (5x5)
Series	-	Rise / Fall Time (Typ)	25ns, 12ns
Packaging	Cut Tape (CT)	Package / Case	24-WQFN Exposed Pad
Other Names	1028-1234-1	Operating Temperature	-40°C ~ 125°C (TJ)
Number of Drivers	6	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	3 (168 Hours)	Logic Voltage - VIL, VIH	0.7V, 3.2V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Input Type	Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap)	15V	Gate Type	N-Channel MOSFET
Driven Configuration	Half-Bridge	Detailed Description	Half-Bridge Gate Driver IC Inverting, Non-Inverting 24-WQFN (5x5)
Current - Peak Output (Source, Sink)	-	Channel Type	3-Phase
